H410H6-M7 | ECS ELITEGROUP Motherboard
$ 64.26
- Description CPU Supports 10th Gen Intel® Core™ family/ Pentium / Celeron series processors for LGA 1200 socket 4 1 Phase Thermal Design Power 100% Solid capacitor design CHIPSET Intel® H410 Express Chipset GRAPHICS Supports DirectX® 12 MEMORY Dual-channelDDR4 Memory architecture Supports DDR4 2666 non-ECC, Un-buffered SDRAM Memory 2 X 288-pin DDR4 DIMM socket Support up to 64 GB* EXPANSION SLOT 1 X PCI Express X16 Gen 3.0 slot(s) 1 X PCI Express X 1 Gen 2.0 slot(s) Storage Support by Intel® H410 Express Chipset 4 X Serial ATAIII 6Gb/s Audio 8-Channel HD audio CODEC Realtek ALC 662 6-channel High Definition audio CODEC LAN Realtek RTL8111H Gigabit Fast Ethernet Controller USB Support by Intel® H410 Express Chipset 4 X USB 3.2 Gen 1×1 port(s) up to 5Gb/s —- Back Panel 2 port(s) —- Onboard 2 port(s) 6 X USB2.0 port(s) Up to 480 Mb/s —- Back Panel 4 port(s) —- Onboard 2 port(s) REAR PANEL I/O 1 X PS/2 combo connector 1 X Audio port (Line Out/Line In/Mic In) 1 X RJ-45 port 1 X HDMI port(s) 1 X HDMI port(s) (optional) 1 X D-Sub (VGA) port(s) 2 X USB 3.2 Gen 1×1 port(s) 4 X USB2.0 port(s) CONNECTORS & HEADERS 1 X 24-pin ATX Power Supply connector 1 X 4-pin 12V Power connector 1 X 4-pin CPU_FAN connector with smart fan 1 X 4-pin SYS_FAN connector with smart fan 1 X Front Panel switch/LED header 1 X Front panel audio header 1 X USB 3.2 Gen 1×1 header Support additional 2 USB ports 1 X USB 2.0 header Support additional 2 USB ports 4 X SATA III 6Gb/s connector(s) 1 X CLR_CMOS header 1 X Serial port header (COM) Support additional 1 Serial Port (COM) 1 X Chassis intrusion header SYSTEM BIOS AMI BIOS with 128 MB SPI Flash ROM F7 hot key for boot up devices option Support GUI UEFI BIOS Plug and Play, STR (S3) / STD (S4) , Hardware monitor, Multi Boot Multi-Language BIOS FORM FACTOR mATX Form Factor 195mm*200mm OS Support Windows 10 64-bit Certifications CE/FCC Certification Bundled Software ECS Intelligent EZ Utility : eBLU, eDLU, eSF
